FAST TO USE
From your screen to real life in minutes, just choose what quality you’d like your model and hit print!
BUILD QUALITY MODELS
We believe in quality. All our materials are produced to industry quality standards so you can rest assured that you will be printing the highest quality 3D models
CHOICE OF PRINT MATERIALS
Choose from a wide range of materials, finishes and colours for your model
FUSED FILAMENT FABRICATION
The Robox® uses Fused Filament Fabrication (FFF) which works in a similar way to a hot-melt glue gun – using plastic filament instead of glue sticks and a digitally controlled head to lay down material layer on layer to make 3 dimensional parts .
AUTOMAKER™ SOFTWARE
The Robox® uses Fused Filament Fabrication (FFF) which works in a similar way to a hot-melt glue gun – using plastic filament instead of glue sticks and a digitally controlled head to lay down material layer on layer to make 3 dimensional parts .
VARIETY OF PRINT FEEDSTOCK
Robox® 3D print feedstock will be available in a variety of materials, finishes and colours and is produced to consistent quality standards. For each material CEL provides a print profile, which will be available in AutoMaker™ to gain the optimum results, setting all of the appropriate parameters for you.
CONSTRUCTION METHODOLOGY
All of the motion axes are coupled to a single sheet metal part, reducing the need for factory calibration and ensuring that your Robox® is perfect for printing straight off the production line.
FEATURES
-
QuickFill™ Dual Nozzle Technology
-
Auto Z Height Calibration
-
‘TapeLess’ High Performance PEI Bed Material
-
HeadLock™ quick change head system
-
Single or Dual Extruders
-
Automatic Material Recognition (SmartReel™) and Instant Loading
-
Automatic Head Recognition
-
Draft Blocking Build Chamber
-
2 minute Fast Heat-up Time
-
Plug and Play - no set up or assembly required
Frame and Case Design
The quality of printing is predominantly dependent on the resolution and accuracy of the motion axes. The printer must be capable of laying down accurate slices of plastic material layer after layer to produce a usable part. We have designed Robox® from scratch, ensuring the frame and motion systems are extremely rigid and accurately positioned. All motors and axes are attached to a single stainless steel frame which is a reference surface for all motion; this is rigidly attached to injection moulded parts which form the body of the printer to create a super-stable platform.
Speed – Dual Nozzle System
Robox® includes a proprietary dual-nozzle system which can improve print speeds by up to 300% when set against our competitors. A single material feed can be directed out of one of two nozzles – with a 0.3mm or 0.8mm extrusion diameter. This means Robox® can produce highly detailed exterior surfaces for the surfaces you can see, and then quickly fill the object using the larger nozzle multiple layers at a time without affecting part strength or detail. This combined with a needle-valve system stops ‘ooze’ and ‘stringing’ from the nozzles – a problem commonly found in other printers. So now you can finally have the best of both worlds – a perfect high quality exterior finish with much faster print times!
Construction Methodology
All of the motion axes are coupled to a single sheet metal part, reducing the need for factory calibration and ensuring that your Robox® is perfect for printing straight off the production line. The use of injection moulded parts combined with sheet metal components produces a very rigid structure, while allowing for a stylish consumer product.
Minimal Inertia
By using a ‘Bowden tube’ extruder, we are able to keep the weight of the printing head to a minimum, allowing for much faster extrusion and travel speeds without affecting print quality.
Large High Torque Stepper Motors with High Resolution Axes
We have over-specified the stepper motors for all the motion axes, meaning Robox® should be able to cope with all future head developments without a hitch. We have used 2mm pitch belt drives for X and Y axes and our own custom machined 0.5mm pitch Z axis screw. All of the motors are custom designed for the printer. This gives us the highest theoretical accuracy on the market, and allows us to achieve super-fine layer height.
Separate Build Chamber and Electronics Enclosure
Due to the heated build platform, we can maintain approximately 50°C ambient temperature in the build chamber. This stable environment helps to maintain part accuracy and print quality by preventing uneven cooling. The problem with this feature is that this ambient temperature can be too hot for the motors and electronics which control the printer. These are all therefore outside the build chamber and actively cooled by outside airflow to keep everything running smoothly.
Automatic Build Platform Levelling
One of the major problems with almost all available 3D printers is that the bed must be manually levelled to ensure the first layer adheres correctly. This is be a fiddly process which has to be regularly repeated – a source of frustration for other 3D printer owners! Well, we’ve solved that. Robox® uses a proprietary bed probing mechanism which can measures the location of the bed before every print. As both Z motors are driven independently they can be adjusted to ensure the X axis is always parallel to the print bed.
Extruder Construction and Feedback Loop
The Robox® extruder contains the world’s first dual-pinch-wheel extrusion system. This allows for very consistent and reliable extruder operation with excellent resolution and control. The filament is fed to the head by two indexed contra-rotating feed wheels which are powered by a worm & wheel gearbox. This arrangement virtually eliminates the possibility of ‘stripping’ your filament, causing a loss of extrusion and poor print quality.
Pause and Resume
The filament extruder incorporates a closed-loop feedback system which monitors the motion of filament as it enters the extruder, giving it the ability to instantly recognise extrusion issues. The software can pause the print if any error is found, allowing the user or firmware to rectify the problem without ruining the entire print. A long awaited feature on 3D printers is ‘resume’ – the user can restart the print and it will continue from where it left off. Another first for Robox®!
Nozzle Valve System
Another problem that we have solved is ‘ooze’ -the stringing and over extrusion at the end of a section of printing. This happens due to the low viscosity of molten plastic. In most printers, this is solved by what is known as a ‘retract’, where the filament is rapidly reversed in conjunction with a very small melt chamber, however this is not always effective. Robox® overcomes this problem through the use of a needle-valve system which completely closes the nozzles at the point of extrusion, removing all stringing and ‘blobs’ from the part – resulting in an amazing surface finish.
SOFTWARE
AutoMaker is the software used to layout your models, view the status of Robox and adjust the settings used during a printing or other operations. AutoMaker is available to download and can be installed in most languages on many operating systems including Windows, MacOS and Linux. Without a Robox attached there is limited functionality, a user can load a .stl or .obj file and manipulate it. Connect a Robox to allow printing in Draft, Normal, Fine or Custom within 3 very simple steps. Opening the Advanced Tray enables a huge array of settings, each is clearly described and sorted into easily recognisable sections. Save custom settings if you want to repeat a print or share it with other users. Custom print settings are saved as text based .roboxprofile files in the users documents folder and a PrintJobs folder is created containing all the settings and code used for every print that is created. The goal from the beginning with AutoMaker has been to make 3D printing easier, we want users to concentrate on designing parts to print, not needing to fiddle with the print settings to try to get a result. Our default settings are tried and tested using our filament and allow even a complete novice user to get a repeatable and consistent result every time. Advanced users have all the control required to satisfy even the most complex print jobs and are able to easily share their custom profiles with all of us.
SOFTWARE
Robox materials are supplied on a SmartReel which holds data about temperature settings, print speed, diameter and even the amount of filament which has been used on that reel. As a user this makes printing very easy, you load the filament and AutoMaker will automatically change to the settings saved on the reel. Robox currently allows users to print in PLA, ABS, HIPS, Nylon, PC and PVA but we are constantly testing more materials. Data on materials and Material Safety Data Sheets (MSDS) are available on our materials page and will be revised and added to as information becomes available. Each release of AutoMaker™ includes the latest filament profiles for each filament, these are updated automatically when an unmodified Robox SmartReel is loaded. We and our users can also share the Filament profiles we create for materials not supplied on a SmartReel, these Filament Profiles are text files ending with “.roboxfilament”. Robox is able to use filament from any brand, we do not lock you into our SmartReel system. Obviously better quality filaments will give consistent results. To use another 1.75mm diameter filament you can just feed it in and tell Robox to get the filament data from a file rather than reading a SmartReel. You can download this file or create your own by copying the default Robox profiles and editing them within AutoMaker or via a text editor. You can also write your saved .roboxfilament data to a SmartReel at any time.
TECHNICAL SPECIFICATIONS
CONSUMABLES AND SPARES
Weight (for shipping) - 0.95kg
Nett Weight - 700g
Filament Diameter - 1.75mm
Length - approx 240m
-
Each reel is sealed in a reusable zip lock bag with a sachet of silica gel to control moisture. The bag is then placed in a sturdy windowed box for shipping.
-
Included on the reel is an EPROM which can be read by a Robox device. The eprom stores data on the material and statistics of use.
Polar White 3DF-RBX-PLA-WH170 |
---|
Dynamite Red 3DF-RBX-PLA-RD536 |
Hot Pink 3DF-RBX-PLA-RD534 |
Highway Orange 3DF-RBX-PLA-OR022 |
Designer Grey 3DF-RBX-PLA-FS391 |
CORNFLOWER BLUE 3DF-RBX-PLA-BL823 |
Mellow Yellow 3DF-RBX-PLA-YL503 |
Amethyst Purple 3DF-RBX-PLA-PP157 |
Chroma Green 3DF-RBX-PLA-GR497 |
Black As Night 3DF-RBX-PLA-BK092 |
Natural Clear 3DF-RBX-PLA-TP001 |
Weight (for shipping) - 0.85kg
Nett Weight - 600g
Filament Diameter - 1.75mm
Length - approx 240m
-
Each reel is sealed in a reusable zip lock bag with a sachet of silica gel to control moisture. The bag is then placed in a sturdy windowed box for shipping.
-
Included on the reel is an EPROM which can be read by a Robox device. The eprom stores data on the material and statistics of use.
Polar White 3DF-RBX-ABS-WH169 |
---|
Dynamite Red 3DF-RBX-ABS-RD537 |
Hot Pink 3DF-RBX-ABS-RD535 |
Highway Orange 3DF-RBX-ABS-OR023 |
Designer Grey 3DF-RBX-ABS-FS390 |
Cornflower Blue 3DF-RBX-ABS-BL824 |
Mellow Yellow 3DF-RBX-ABS-YL504 |
Amethyst Purple 3DF-RBX-ABS-PP156 |
Chroma Green 3DF-RBX-ABS-GR499 |
Black as Night 3DF-RBX-ABS-BK091 |
Crystal Clear 3DF-RBX-ABS-TP001 |
3DS-RBX-RBX01-SMSingle Material Dual Nozzle Head |
---|
3DS-RBX-RBX01-X1Extruder Consists of : RBX1-EX1 Extruder, Bowden tube assembly, Cable to connect to Robox Main PCB |
3DS-RBX-RBX01-RBX01-DM KitDual Material Head + 2nd Extruder to fit CEL Robox® Micro manufacturing platform NOTE: First production stock now sold out. Orders from this time will be from the 2nd batch which will be produced a few weeks later. |
3DS-RBX-RBX01-PEI-R1Robox ThermoSurface™ Print surface replacement NOTE: If your existing bed does not have the tabs shown in the image please select the product RBX01-PEI-R1 instead. |
3DS-RBX-RBX01-PEI-R1Robox ThermoSurface™ Print surface revision 1 replacement NOTE: If your existing bed has tabs around the edge please select the product RBX01-PEI instead. |
3DS-RBX-RBX01-RLEmpty Filament Reel with blank EEPROM |
3DA-RBX-RBX01-ACC-TKTK Robox Carving Tools - set of 4 |
---|
3DA-RBX-RBX01-ACC-TWRobox Tweezers |
3DA-RBX-RBX01-ACC-LGAxis Lubricant |
3DA-RBX-RBX01-ACC-FDAutoMaker USB 2.0 Drive |
3DA-RBX-RBX01-ACC-AWPack of 10 Alcohol Wipes |
